High-Power WiFi 6E RF Jammer Amplifier Module with 50W or 100W Output for 5925-7125 MHz Signal Suppression

  • 1
  • 2

Brand Name : PTC

Model Number : PTC-A6E

Certification : CE,QS

Place of Origin : SHENZHEN CHINA

MOQ : 1PCS

Price : Neg

Payment Terms : T/T, Western Union, L/C, D/A, D/P

Supply Ability : 50000/M

Delivery Time : 5-30days

Packaging Details : Standard Packing

Contact Now

High-Power WiFi 6E 5925 - 7125MHz RF Jammer Amplifier Module with 50W 100W Output
As the wireless landscape evolves, the WiFi 6E (6GHz band) presents new security challenges. Our industrial-grade RF Jammer Module is specifically engineered to provide robust signal suppression across the entire WiFi 6E spectrum (5925-7125 MHz). Featuring high-efficiency GaN technology and a compact form factor, this module is the ideal core component for advanced signal management systems, prison security, and sensitive area protection. The 50W 6E WIFI RF amplifier module is a no signal source amplifier module, designed to be lightweight and easy to mount and carry.
Technical Specifications
Parameter Specifications (Standard) Specifications (High Power)
Model A6E-50W A6E-100W
Frequency Range 5925 - 7125 MHz (Full WiFi 6E Coverage) 5925 - 7125 MHz
Output Power 50W (47 ± 1 dBm) 100W (50 ± 1 dBm)
Modulation Source Digital Gaussian Noise / Analog Sweep Digital Gaussian Noise / Analog Sweep
Input Voltage DC +28V / +48V Optional DC +28V / +48V Optional
Operating Current < 6A (at 28V) < 12A (at 28V)
RF Interface N-Female (Output) / SMA (Input) N-Female (Output) / SMA (Input)
Control Interface DB9 / DB15 (Customizable) DB9 / DB15 (Customizable)
Cooling System Integrated Heat Sink (Fan cooling required) Advanced Forced Air Cooling
VSWR Protection Built-in Auto-Shutdown Protection Built-in Auto-Shutdown Protection
Key Features
  • Cutting-Edge Frequency Coverage: Targets the latest WiFi 6E 6GHz band, ensuring no security blind spots.
  • Optional Power Outputs: Choose between 50W for standard range or 100W for ultra-long-distance suppression.
  • High Stability: Maintains consistent output power even in extreme temperatures (-20°C to +65°C).
  • Smart Protection: Features over-temperature and high-VSWR (standing wave) protection to prevent hardware damage.
  • Customization (OEM/ODM): Tailored frequency ranges, gain adjustments, and housing designs available upon request.
Product Applications
  • Counter-UAV Systems: Effective against drones utilizing the 6GHz control/video downlink.
  • Sensitive Facility Security: Prisons, Gas plant, and government buildings.
  • Privacy Protection: Prevention of unauthorized WiFi 6E data transmission in corporate boardrooms.
High-Power WiFi 6E RF Jammer Amplifier Module with 50W or 100W Output for 5925-7125 MHz Signal Suppression High-Power WiFi 6E RF Jammer Amplifier Module with 50W or 100W Output for 5925-7125 MHz Signal Suppression
Keywords: WiFi 6E Jammer, 6GHz RF Module, 100W Signal Suppressor, 50W RF Power Amplifier, WiFi 6E Security, High Power Jammer Source.
